Material Properties:
1. High purity
2. High duribility
3. High Temperature Resistance(working temperature 1100℃)
4. Flame polished
5. Acid and alkali resistance
Product Details
1. SiO2> 99.99% ,high purity quartz tube. 2.Operating Temperature: 1250℃ SoftenTemperature: 1730℃.
3.Excellent visual and chemical
performance .
4. without surface coating and infectant.
5. Health care and environmental protection. 6. Any dimension can be made.
7. CE.RoHs SGS approved.
Further processing:
Flame polishing/optical polishing/grind
Standard ground joint:9mm/14mm/18mm/19mm/24mm/29mm
We adopt continue melting method,rotation method, flame melting method to produce various kinds of transparent.Meanwhile,we have Arc quartz crucible workshop,old process workshop, fire process workshop, so that we can accept higher requirements to customize all kinds of quartz glass products, such as Quartz tube, Quartz plate, Quartz crucible, Quartz flange, Furnace quartz tube, Quartz boat, Laboratory quartz instruments, Quartz heater and other related quartz glass products.These products are widely used in semiconductor, photovoltaic, infrared heating, flight, chemical, and large colleges and universities in the laboratory and other industry fields.
Accept customized drawings and samples:
Factory support to figure to sample custom, Ultraviolet sterilizing lamp, ultraviolet sterilization tube, ozone sterilization lamp shade, etc
product is mainly used in electric light source, electrical appliances (electric), semiconductor, optical communications,
military industry, metallurgy, building materials, chemical, machinery, electricity, environmental protection and other fields
| Round type | Diameter: 1mm-500mm;
Thickness: 0.5mm-300mm. |
| Rectangle type | Length: 5mm-2000mm;
Width: 5mm-800mm;
Thickness: 0.5mm-100mm |
| Thickness tolerance | ±0.02-0.1mm |
| Compressive strenth | 1100Mpa |
| | |
| Young’s modulus | 72000Mpa |
| Modulus of rigidity | 31000Mpa |
| Index of refraction | 1.4585 |
| Electrical resistivity:1000℃ | 1x106 Ω. cm |
| Hardness | 5.5 - 6.5 Mohs' Scale 570 KHN 100 |
| Softening point | 1683℃ |
| Annealing point | 1215℃ |
| Strain point | 1120℃ |
Company profile:
Lianyungang Shengfan Quartz Product Factory is a professional manufacture specialized in research and development of quartz plate,quartz tube,quartz flange,quartz ring,cuvette and quartz instrument. The company is located in China Crystal Capital - Donghai City, Jiangsu Prov., China. 70 km far from Lianyungang port, convenient transportation.
